Greater flexibility thanks to secure tool systems and setting-up procedures for all aspects of tube processing
The demand for greater process flexibility in tube manufacturing keeps growing. That includes minimizing idle time, such as the set-up time, from the very start to the first finished component that meets the specifications. During the set-up time the chances of the operator making a mistake should be minimized or even completely eliminated. Therefore, the processes need to be secured and there shouldn“t be any possibility of a tool mix-up.
The Japanese principle of „Poka Yoke“ teaches us that it is possible to prevent errors by incorporating multiple elements with technical features, such as immediate detection and prevention of errors. This is particularly important in the case of complex machines and production units that have to meet exacting demands.
Systems to get into the right position and geometry
To achieve an even safer and more effective tube production, the solution-finders at machine manufacturers transfluid have further developed and improved their whole product range. With the t bend bending machines it is no longer necessary to make any manual adjustments on electrically powered units. Bending tools can be mounted securely on the bending machine to reduce set-up time. In addition to that, all tool components can be assigned a code in a corresponding system. This coding ensures that the right tools are used for the product and that they are positioned correctly; it also ensures that the parameters for the required geometry are applied.
Checking that the right equipment is being used can be done either with a manual scanner or automatically. Special crease smoothers can now locate their exact position again, with accuracy and no manual intervention, thanks to the positioning with brushless drives motors.
„These secure tool systems and set-up processes are suitable for our bending machines and also for most of the forming machines. I am happy to see how we have achieved our goal of delivering faster and safer set-up processes to our clients“, sums up transfluid director Stefanie Flaeper. The set-up times for the first, accurate part can be measured in single-digit minutes for standard tubes with 90mm diameters. An actual example comes from a t bend machine that bends counterclockwise and and clockwise, for the production of tubes with diameters of up to 30mm. In this case the operator can set up the tools for the left and right production areas in just three minutes. This achieves the objective of high and reliable flexibility and minimization of the set-up time.
transfluid Maschinenbau GmbH – the solution for tubes
transfluid is sought after worldwide as a partner for manufacturing tube bending machines and tube processing machines. Since 1988 transfluid has been further developing its technologies for tube machining, so that it can provide customer-oriented, tailor-made solutions – for plant and machine construction, the automotive and energy industries,
shipbuilding and medical device manufacturing.
transfluid’s product portfolio offers perfect solutions in five different machine categories, that meet all the requirements in tube processing. t bend stands for a wide range of tube bending machines, which fulfil the highest demands in terms of industrial applications. The tube forming machines in the t form range offer the perfect tube shaping solutions. Tube forming is important as an individual or supplementary process, in order to obtain optimally tailored tubes. Automation systems are offered as fully developed concepts for bending and forming technology, under t motion. t cut covers the field of tube cutting machines. Here, transfluid is able to provide a range of different systems, for example for chipless orbital cutting and special knive separation processes. The category t clean encompasses tube cleaning machines. These ensure the cleanliness of workpieces and tubes. Additionally, with the new tu go range, transfluid offers a standardised portfolio of machinery, which is available from stock for immediate delivery. transfluid offers the powerful software t project for rapid and reliable tube processing. It can be used as an effective online solution for bending machines and the majority of CAD systems.
